interface RS-232, RS-485, USB, LAN, Analogue 4-20 mA, 0-10 V, OC optional
Highlights
- Completely made of stainless steel IP67-IP65
- Unit Counter
- Summation function
- MAX. / MIN. indication
- Percentage weighing
- Formula weighing
- Animal weighing function
- Gross / Net display
- Tare storage
- Threshold weighing MIN / MAX / OK
- 3 potential-free contactors
- Analogue output optional 4-20 mA / 0-10 V
Specification
|
|||||||||||||||||||||||||||||||
| * The minimum load is defined by the load, from which the calibration authority tests the accuracy of the scale. The waterproof steel scale shows even lower weights, but these are not valid for custody transfer. | |||||||||||||||||||||||||||||||
| Calibration Class | M III (is delivered calibrated) | ||||||||||||||||||||||||||||||
| Unit Counter Function | counting by reference values | ||||||||||||||||||||||||||||||
| Tare function | multiple taring covering the whole measurement range | ||||||||||||||||||||||||||||||
| Interface | optional bi-directional RS-232, USB, LAN datasheet on interface as well as analogue output 4-20 mA, 0-10, OC |
||||||||||||||||||||||||||||||
| Display | LED with 20 mm digit height | ||||||||||||||||||||||||||||||
| Cable Length | from platform to display | ||||||||||||||||||||||||||||||
| Power Source | ~230V, 50Hz, 8VA (schuko plug) | ||||||||||||||||||||||||||||||
| Protection Class | IP 67 cell / IP65 display | ||||||||||||||||||||||||||||||
| Operational Temperature | -10 °C ... +40 °C | ||||||||||||||||||||||||||||||
| Weight | platform 400 x 500 x 120 mm / 17 kg platform 600 x 500 x 135 mm / 25 kg |
||||||||||||||||||||||||||||||
