3x optical zoom, detection distance up to 3100m
TJ LRF Zoom Series adapts a 20mm~60mm dual FOV lens, which allows for easily changing the focal lengths and focus fine-tuning. It is a perfect combination of large-scale and long-distance observation, capable of detecting targets up to 3100m.
12μm IR detector, NETD down to 15mK
By utilizing a highly sensitive IR detector with a NETD down to 15mK, even the slightest temperature differences can be distinguished, resulting in sharper and clearer imaging.
Easily changing the focal lengths
With the well-designed focus ring, TJ LRF Zoom Series allows users to smoothly switch the focal lengths from 20mm to 60mm within 1 second, and fine-tune the focus to get the perfect image of targets.
Ultra-large displayOptimal visual experiences
Optimal visual experiences To present a better visual experience, hence improving the efficiency and comfort of outdoor exploration, TJ LRF Zoom has upgraded the display to provide a stunning visual effect like a 70-inch home theater at 2.5m distance.
1000m laser rangefinder
The built-in laser rangefinder provides a long detection range of up to 1000m, improving the capability to obtain the target distance and the long-distance perception.
Intelligent sleep mode
TJ LRF Zoom developed an intelligent function of automatically switching the sleep mode and wake up mode by recognizing the device’s posture, which will lead to lower power consumption and longer battery life.
Specifications
| Specification | TJ660LZS |
|---|---|
| Product Model | ![]() |
| Sensor | |
| Core technology | Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm Hyper-Light 2.0 |
| Type | Uncooled VOx Infrared Detector, 8 to 14µm |
| Resolution | 640×512@12µm |
| NETD | 15mK |
| Frame rate | 50Hz |
| Lens | |
| Objective lens | 20mm, F0.9; 60mm, F1.1 |
| Field of View | 21.7×16.4; 7.3×5.5 |
| FOV m@100m | 38×29; 13×10 |
| Magnification | 1.2x~9.6x; 3.5x~28x |
| Detection range | 1000m/1090yd; 3100m/3350yd |
| Focus | Manual |
| Display | |
| Display type | 0.39'' AMOLED 1920×1080 |
| Color palettes | White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia |
| Eyepiece | Eye relief: 20mm; Diopter: -6 to +6; Zoom: 13.8x |
| Hardware | |
| Laser rangefinder | 1000m/1090yd |
| Wi-Fi | 2.4G, 5G |
| Interface | USB-C (Power supply/USB2.0) |
| Others | Microphone, Compass, Gyroscope, Bluetooth |
| System | |
| Recording function | Photo/Video (Audio recording included) |
| Storage capacity | 128 GB |
| Power | |
| Battery type | 2 Replaceable 18650 Batteries |
| Operating time | 10 hours |
| Environmental | |
| Operating temp. | -20°C to 50°C / -4°F to +122°F |
| IP Rating | IP67 |
| Physical | |
| Weight (g/oz) | 764/26.95 |
| Size (mm/in) | 259×97×69/10.20×3.82×2.72 |
| Standard | Device, Hand Strap, Neck Strap, Lint-Free Cloth, 18650 Battery ×2, Battery Charger, 5V 2A Adapter, USB-A to USB-C Cable, Quick Start Guide, Warranty Card |
| Optional | Bluetooth Remote Control, 18650 Battery |
