chieve Precision and Safety with a Professional Electrostatic Field Meter

The ESF-106 Electrostatic Field Meter provides accurate and reliable measurements of static voltage, making it an essential tool for various industrial, environmental, and safety applications.

Exceptional Features of the ESF-106:

1. High Precision Measurement: Specially designed for measuring static voltage with 0.001 kV resolution, offering high accuracy and reliability.

2. Built-In Alarm Setting: Equipped with an alarm that can be set from 0.010 kV to 18.000 kV, indicating high voltage levels and ensuring safety.

3. Data Hold and Memory Recall: Includes data hold to freeze the display reading and memory recall for maximum and minimum values, ensuring critical data is recorded.

4. User-Friendly Design: Equipped with a large LCD display with green backlight for easy reading, and user-friendly controls including zero adjustment and over-input indication.

5. Advanced Connectivity: Includes RS232/USB computer interface for data output, enhancing data management and integration with other systems.

Technical Specifications:

- Display:

  - Type: LCD with green backlight (On/Off)

  - Size: 51 mm x 30 mm

  - Max Indication: ±19999

- Measurement Functions:

  - Static Voltage:

    - Range: -19.999 kV to +19.999 kV

    - Resolution: 0.001 kV

    - Accuracy: ±(5% + 50d) @ 23 ± 5℃

- Data Output:

  - RS232/USB PC Computer Interface

- Sampling Time: Approx. 0.5 second

- Power Supply:

  - DC 9V battery (006P, MN1604 or equivalent)

  - Power Consumption: Approx. DC 6 mA

- Operating Environment:

  - Temperature: 0 to 50℃ (32 to 122℉)

  - Humidity: Less than 80% RH

- Dimensions:

  - Size: 195 x 68 x 30 mm (7.6 x 2.6 x 1.2 inches)

  - Weight: 215 g (0.476 lb)

Accessories Included:

- Instruction Manual: 1 PC

- 1" Magnetic Spacer: 1 PC

- Ground Wire: 1 PC

- Ground Clip: 1 PC

- Carrying Case (CA-06): 1 PC

Optional Accessories:

- USB Cable (USB-01)

- RS232 Cable (UPCB-02)

- Data Acquisition Software (SW-U801-WIN)

- Excel Data Acquisition Software (SW-E802)

Advanced Features:

- Microprocessor Circuit: Ensures high accuracy and reliability.

- Zero Adjustment: Easy zero adjustment with a dedicated button.

- Over-Input Indication: Displays "----" when the input exceeds the measurement range.

- Alarm Setting: User-definable alarm setting for high voltage detection.

Applications:

- Industrial Safety: Monitors static voltage in various industrial applications.

- Environmental Monitoring: Measures electrostatic fields in different environments.

- Health and Safety: Ensures safety in workplaces by detecting high static voltage levels.

Invest in the ESF-106 Electrostatic Field Meter for precise and reliable static voltage measurements, ensuring high performance and safety in various industrial, environmental, and safety applications.
