The Protekt Parapet Anchor Point AT254 is designed for securing up to 2 users simultaneously, offering reliable fall protection on firewalls, sheet metal, and other structures. Made from durable steel with a robust galvanized finish, this anchor point provides a static strength of 12 kN, ensuring safety in high-risk environments.

The 700 x 350 x 100 mm frame is designed for easy mounting on firewalls, window sills, or walls with a minimum thickness of 12 mm. The anchor point features a movable slider with five adjustable positions (100mm spacing), secured with a pressure screw to firmly press the frame against the structure. This ensures a secure and versatile anchorage for personal fall protection.

Note: The device must be mounted on the upper edge of the object; attachment from the side or below is not permitted.

Specifications:

• Material: Steel
• Finish: Galvanized
• Dimensions: 700 x 350 x 100 mm
• Weight: 10.5 kg
• Static Strength: 12 kN
• Bore Diameter of the Catch Point: 60 mm
• Spacing Min.: 12 mm
• Spacing Max.: 468.5 mm
• Max. Number of Users: 2
• Application: Anchoring on firewalls, sheet metal, and walls (min. 12 mm thickness)

Safety and Usage Guidance:

Ensure the anchor point is properly installed at the upper edge of the structure, following the installation guidelines. Regularly check the slider and pressure screw for tightness and wear. Use only for personal fall protection and do not mount from the side or below.
