YOUNGSHINE IVIEW+ AI Pedestrian Detection Camera System

The Youngshine IVIEW+ is an AI-powered pedestrian detection camera system designed for industrial vehicles, providing real-time human detection with visual and audible alerts. Using deep learning technology, the system detects pedestrians and alerts drivers through a 7-inch HD monitor and high-powered 92dB sound warning to reduce accident risks in warehouses, factories, construction sites and other industrial environments.

The system automatically extracts human figures from the environment and allows adjustable detection range settings with up to four depth zones. When a pedestrian is detected, a red box appears on the display together with an LCD/LED alert and beep sound. An external siren is provided to enhance audible alerts, with optional speaker support available.

Specifications

Monitor

• Screen Size: 7 inch TFT / 1024 × 600

• Colour Depth: 16.7M

• Operating Voltage: DC 12V ~ 48V

• Operating Temperature: -20°C to 65°C

• Dimension / Weight: 225 × 140 × 70mm (W × D × H) / 1.03kg

• Buttons: 5 buttons with LED backlight

• Camera Input: Up to 2 channels

• Video Input: Composite Video (CVBS) 75Ω 1Vp-p

Camera

• Image Sensor: 1/4" Colour CMOS Image Sensor

• View Angle: 132° (D), 100° (H), 76° (V)

• Operating Voltage: DC 12V (via monitor)

• Operating Temperature: -40°C to 105°C

• Dimension / Weight: 60 × 35 × 48mm (W × D × H) / 0.98kg

• Waterproof Rating: IP69K

• Video Output: Composite Video (CVBS) 75Ω 1Vp-p

Alert System

• 92dB high-powered sound

• Volume control

• External siren included

• Optional voice support / speaker compatibility

Applications

Suitable for industrial vehicles including forklifts, excavators, wheel loaders and tractors. Recommended for use in warehouses, factories, construction sites, mining sites and ports.

Note: Specifications may be changed for product improvement. Ensure compatibility with vehicle voltage before installation.
