Manufacturer Specs
| Specifications | |||
| Classification | DIN 5032-7: 1985 class B JIS C 1609-1: 2006 general AA class |
||
| Light receiving element | Silicon photodiode | ||
| Display | Display: 4 digit, 2000 count LCD Display unit: lx (lux) Display update rate: 500 ms ±20 ms |
||
| Measurement ranges | Range | Measurement range | Display step |
| 20 lx | 0.00 lx to 20.00 lx | 1 count/step | |
| 200 lx | 0.0 lx to 200.0 lx | ||
| 2000 lx | 0 lx to 2000 lx | ||
| 20000 lx | 00 lx to 20000 lx | 10 counts/step | |
| 200000 lx | 000 lx to 200000 lx | 100 counts/step | |
| Range selection | Auto/Manual | ||
| Linearity | ±2% rdg. (Multiply by 1.5 for display values in excess of 3000 lx.) | ||
| Accuracy guarantee conditions | Sensor unit and display unit must bear the same collation number. | ||
| Accuracy guarantee for temperature and humidity |
21°C to 27°C (69.8°F to 80.6°F), 75% RH or less (non-condensing) | ||
| Temperature characteristics | ±3% rdg. | ||
| Humidity characteristics | ±3% rdg. | ||
| Accuracy warranty period | 2 years | ||
| Response time | Auto range: within 5 seconds Manual range: within 2 seconds |
||
| Power supply | AA/LR6 alkaline battery × 2 R6 Manganese battery × 2 USB bus power 5V DC |
||
| Continuous battery operation time | Approx. 300 hours (when using AA alkaline batteries) | ||
| Auto-power off | Turns off the instrument 10 min. ±1 min. after the last key operation (can be canceled). |
||
| Operating temperature and humidity | -10°C to 40°C (14°F to 104°F), 80% RH or less (non-condensing) | ||
| Storage temperature and humidity | -20°C to 50°C (-4°F to 122°F), 80% RH or less (non-condensing) | ||
| Operating environment | Indoors, pollution degree 2, altitude up to 2000 m (6562-ft.) | ||
| Applicable standards | Safety: EN61010, EMC: EN61326 | ||
| Standard compliance | DIN 5032-7: 1985 class B JIS C 1609-1: 2006 general AA class |
||
| Dustproof and waterproof | IP40 (EN60529) | ||
| Dimensions and mass | Approx. 78W × 170H × 39D mm (3.07″ W × 6.69″ H × 1.54″ D) Approx. 310 g (10.9 oz.) (including the batteries) |
||
| Accessories | Instruction Manual ×1, AA/LR6 alkaline battery ×2, Sensor cap (with strap) ×1, Carrying case (soft) ×1, Strap ×1, USB cable (0.9 m) ×1, CD-R (USB driver, dedicated computer application software, and communications specifications) ×1 |
||
